Stack SERIES

7245LA
Battery Pack

Review the catalogue data, then discuss your installation and operating requirements.

Imported from existing project records, not independently reverified in this prototype. Product imagery is not evidence of compatibility or performance.

DISCUSS THIS MODEL

Catalogue specifications

Nominal voltage	76.8V
Rated capacity	40AH
Rated energy	3072Wh
Charge voltage limit	87.6V
Discharge cutoff voltage	57.6V
Maximum charge current	20A
Maximum discharge current	50A
Discharge temperature	-20℃~60℃
Charge temperature	-10℃~55℃
Communication	Bluetooth
Ingress protection	IPX5
Weight	19.9±0.6kg
Compatible motor power	≤1500W

Source record: p11-02 · Existing product catalogue dated 2026-05-09. Check the original manual and drawing before purchase.

Before selecting this pack

Confirm system voltage, charger settings, continuous and peak current, enclosure dimensions, connector orientation, communication and mounting. No universal vehicle compatibility is implied.
